MRP-64 is a multi-room audio control processor from RTI that can be connected to multi-zone audio/video receivers for simple and quick control
The MRP-64 is a compact, high‑performance control processor for multi‑room audio systems. It provides six panel ports for power and signal, multiple infrared I/O, programmable 12 VDC trigger outputs, and Ethernet and USB programming interfaces.
The manual covers the device’s main functions, hardware interfaces (RS‑232, RS‑485, RJ45, USB, Zigbee), power specifications, protection features, and step‑by‑step installation diagrams. It also explains how to program the unit using RTI’s Integration Designer™ software and how to configure infrared and trigger inputs. This manual is written in Chinese.
| Panel ports | 6 |
|---|---|
| RS‑232 interfaces | 3 |
| Programmable 12 VDC trigger outputs | 3 |
| Voltage‑sensing inputs | 3 |
| Infrared output ports (addressable) | 4 |
| High‑power infrared output (addressable) | 1 |
| Programming interfaces | USB and Ethernet |
| Dimensions (W × H × D) | 132 mm × 52 mm × ? mm |
| Weight | 907 g |
The MRP‑64 provides three RS‑232 interfaces for bidirectional communication.
The unit can be programmed via USB or Ethernet using RTI’s Integration Designer™ software.
Yes, it includes an RTI Zigbee transceiver module for bidirectional wireless communication.
