The XP-3 Control Processor is a powerful remote control processor that is designed to improve the performance and automation of smaller home and commercial installation electronics. With a powerful 533MHz CPU and 128MB of non-volatile flash memory, the XP-3 offers a higher level of control and automation than what is possible with standalone remotes, improving the overall user experience. The processor host has a number of powerful features that set it apart from the competition, including an integrated astronomical clock for time-based events and support for two-way communication with compatible RTI remotes using ZigBee® wireless technology. The XP-3 brings rock-solid control and automation to today's complex, sophisticated electronic environments.
The XP-3 is a powerful control processor designed for home and commercial electronic installations. It features a 533 MHz 32‑bit CPU, 128 MB non‑volatile flash, a built‑in 2.4 GHz Zigbee transceiver, infrared output ports, programmable relay outputs, voltage‑sensing inputs, a dual‑direction RS‑232 port, and Ethernet connectivity.
Programming is performed with Integration Designer software via USB 2.0 or Ethernet, and the non‑volatile flash retains system configuration after power loss. The unit supports firmware upgrades in the field and includes a built‑in astronomical clock for time‑based events and sleep scheduling. This manual is written in Chinese.
| Power Supply | +12 VDC, 1 A |
|---|---|
| Wireless | IEEE 802.15.4 Zigbee (2.4 GHz) |
| RF Frequency Range | 2.4 GHz – 2.5 GHz |
| Infrared Output Ports | 2 ports, 3.5 mm connector |
| Infrared Frequency Range | 15 kHz – 460 kHz |
| RS‑232 Port | 1 |
| Ethernet Port | 1 RJ45, 10/100 Base‑T |
| Voltage Sensing Inputs | 2 inputs, 3‑24 VDC |
It includes a built‑in 2.4 GHz transceiver module that operates with Zigbee (IEEE 802.15.4) technology.
