This manual provides detailed instructions for installing and configuring the Founder 8300 RAID Card in Founder server systems. It covers safety measures, PCI‑X slot selection, SAS cabling, driver installation, and use of the WebBIOS and Power Console Plus management utilities.
The document also includes a troubleshooting section that explains normal hard‑drive indicator behavior during RAID initialization and guidance for handling failed drives in supported RAID levels. This manual is written in Chinese.
| RAID control chip | Intel 80321 |
|---|---|
| Cache | 128 MB SDRAM |
| Supported RAID levels | RAID0, RAID1, RAID5, RAID1+0 |
| Management software | WebBIOS Configuration Utility, Power Console Plus |
The flashing indicates the RAID array is being initialized, which is normal and may last from minutes to hours depending on the array type and size.
If the array uses RAID1, RAID5, RAID1+0 or RAID0/5, data remains intact; follow the manual’s repair steps and back up data before fixing the array.
