This document is an installation and user manual for a brand of scanner. The manual provides detailed instructions on software and hardware installation, system requirements, scanner features, scanning procedures, maintenance and troubleshooting.
This manual introduces the Founder Anyscan Z3000 scanner, lists the original accessories, and explains the system requirements for Windows 2000/XP/Vista PCs. It guides users through hardware setup, software installation, and basic scanning procedures using TWAIN, DI Capture or the scanner’s own buttons.
The document also covers routine cleaning, calibration, power control, safety precautions, and a FAQ section. An appendix supplies full technical specifications and the company’s service‑commitment policy. This manual is written in Chinese.
| Optical resolution | 1600 dpi |
|---|---|
| Color scan depth | 48‑bit input / 24‑bit output |
| Gray scan depth | 16‑bit input / 8‑bit output |
| Black‑and‑white scan depth | 1‑bit |
| Lamp type | Cold cathode |
| Maximum scan area | 304.8 x 431.8 mm (12" x 17") |
| Power input voltage / frequency | 100‑240 Vac, 47‑63 Hz |
| Output voltage / current | 24 Vdc, 1.67 A |
| Power consumption (idle) | 4 W |
| Operating temperature | 5 °C to 35 °C |
| Operating humidity | 20 % to 80 % (non‑condensing) |
| Dimensions (W×D×H) | 623 x 400 x 133 mm (24.53" x 15.75" x 5.24") |
| Weight | 7.5 kg |
Connect the supplied USB cable to the scanner’s USB port and then to a USB 2.0 port on the computer.
