Haier XQJ100-96 Washing Machine Service Manual

This manual provides detailed instructions on the features and performance of the Haier full automatic washing machine XQJ100-96, including safety precautions, product features, technical specifications, installation and maintenance.

Brand
Haier
Document type
Service Manual
Language
Chinese
Pages
15
File format
PDF
File size
1.2 MB
Published
17 October, 2023
Updated
17 October, 2023
MD5 checksum
529FCFC226820336DF7CD50B92C2C93A
PDF
Haier XQJ100-96 Washing Machine Service Manual PDF

About this manual

This service manual covers the Haier XQJ100-96 full‑automatic washing machine. It includes detailed specifications, safety precautions, installation instructions, wiring diagrams, exploded views, and a complete parts list.

The document also provides troubleshooting procedures for common issues such as drainage problems, excessive noise, and low water pressure, helping service technicians diagnose and repair the appliance efficiently. This manual is written in Chinese.

What's inside

  • Features
  • Safety Precautions
  • Warning and Cautions
  • Installation and Accessory Parts
  • Parts and Functions
  • Maintenance Service and Trouble Shooting
  • Wiring Diagram
  • Exploded View
  • List of Parts
  • Specifications

Specifications

Wash capacity10.0 kg
Spin capacity10.0 kg
Voltage / Frequency120V / 60Hz
Wash power800 W
Spin power780 W
Height1115 mm
Width686 mm
Depth686 mm
Net weight73 kg
Download PDF (1.2 MB)
