Spectrodensitometer FD-7 and FD-5 with SpectraMagic NX Guide

About this manual

This document provides instructions for using the Konica Minolta Spectrodensitometer models FD-7 and FD-5 in conjunction with SpectraMagic NX Ver. 2.4 or higher. It details specific operational exceptions, such as the requirement for firmware version 1.20.0000 or later on the instrument.

What's inside

• General operation
• Driver installation
• Connection
• Instrument Settings
• Measurement Meaning
• Calibration
• Data handling

Frequently asked questions

What firmware version is required for the FD-7 or FD-5 to work with SpectraMagic NX?

The instrument firmware must be Ver. 1.20.0000 or later.

Can multiple FD-7 or FD-5 units be connected to a single PC?

No, connection to multiple units is not possible; the software connects only to the first unit found.

Is it necessary to hold the instrument down against the subject when using a target mask?

Yes, you must keep the instrument pressed down until measurement is completed for accuracy.
