XL6008 is a switch current boost/buck type DC-DC converter with wide input voltage range, positive or negative output voltage programming, and high transient response.
The XLSEMI XL6008 is a wide input range current mode DC/DC converter capable of generating positive or negative output voltages. It can be configured as a boost, flyback, SEPIC, or inverting converter. The device features an integrated N-channel power MOSFET and a fixed frequency oscillator, making it suitable for portable electronic devices and industrial applications. This manual is written in Chinese.
| Input Voltage Range | 3.6V to 32V |
|---|---|
| Switching Frequency | 400 KHz |
| Switch Current | 3A |
| Maximum Output Switch Voltage | 60V |
| Reference Voltage | 1.25 V |
| Maximum Efficiency | 92% |
| Package Type | TO252 -5L |
| Operating Junction Temperature | -40 to 125 oC |
The XL6008 is designed for automotive and industrial converters as well as portable electronic devices.
The maximum efficiency of the XL6008 is up to 92%.
The XL6008 has a fixed switching frequency of 400 KHz.
