This document introduces the parameter table, user manual, operating instructions, reference manual, and product samples of the MICROMASTER 420 general-purpose inverter. The main content includes installation, debugging, control methods, system parameters, fault troubleshooting, etc. It also provides technical specifications and optional accessories for the inverter.
The provided text is the Chinese version of the Parameter Table (Version 12/01) for the Siemens MICROMASTER 420 General-Purpose Inverter. It serves as a reference guide containing detailed explanations and descriptions of all parameters required to implement the drive's functions.
The document includes functional diagrams, Binary Interconnect (BiCo) function details, communication protocols, information on Advanced Operator Panels (AOP), installation drawings, and references to other manuals such as the Operation Manual for installation and debugging instructions. This manual is written in Chinese.
| Software Version | V1.1 |
|---|---|
| Document Order Number | 6SE6400-5AA00-0BP0 |
The document specifies that the inverter software version is V1.1.
The manual specifies that the software version for this unit is V1.1.
You must wait at least 5 minutes after turning off the power to open the equipment safely.
If a residual current device is used, it must be Type B (B型RCD).
