This document is an instruction manual for HYDRAMASTER sandblaster, which introduces the usage methods, precautions, maintenance and maintenance of the sandblaster.
The HydraMaster Spitfire 3.2 is a truck-mounted carpet cleaning plant designed to perform multiple functions simultaneously, including engine operation, vacuuming, water pumping, chemical injection, and heating. The system utilizes a dynamic heating system with three separate exhaust heat exchangers to capture free heat and maintain proper water temperature for cleaning.
| Frame Dimensions | 22"W x 29"L x 27"H |
|---|---|
| Weight | 350 lbs. |
| Engine | Vanguard 14 HP Briggs and Stratton |
| Vacuum Blower | Roots 33 RAI |
| Chemical System | Electro-mechanical, meter controlled |
| Recovery Tank Capacity | 50 Gallon |
| Chemical Flowmeter Range | 0-10 GPH |
The manufacturer uses a specific symbol throughout the manual to warn of possible injury or death.
The Spitfire 3.2 weighs 350 lbs.
The liquid-filled water pressure gauge has a range of 0-1000 PSI.
Add oil when the level reaches half way down the sight glass.
