Encoder Products Company Inc. (EPC) is a leading designer and world-wide manufacturer of motion sensing devices. Their popular Accu-Coder™ brand is the most complete line of incremental and absolute shaft encoders in the industry. They specialize in encoder design and have introduced many innovative products that have become industry standards.
The Model 802S Accu-Coder is a heavy-duty, industry standard Size 20 (2.0" diameter) encoder specifically designed for harsh factory and plant floor environments. It features a type 316 stainless steel enclosure, making it ideal for applications where contamination or exposure to caustic chemicals is a concern.
This ultra-rugged yet compact encoder provides precise, reliable output with up to 30,000 CPR. It is available with various flange and servo mounting styles and includes heavy-duty double shielded ball bearings rated at 80 pounds maximum axial and radial shaft load.
| Material | Type 316 Stainless Steel |
|---|---|
| Max Axial Shaft Load | 80 lb max. |
| Max Radial Shaft Load | 80 lb max. |
| Operating Temperature (Standard) | 0° to 70° C |
| Max Shaft Speed | 8000 RPM |
| Weight | 1.5 lb typical |
Common applications include Food Processing, Oil, Gas & Chemical Processing, Material Handling, Conveyors, Robotics, Elevator Controls, and Textile Machines.
The encoder is available with a variety of flange and servo mounting styles.
