The Semtech STF701 is a thin-film-on-silicon device designed to provide bi-directional unwanted EMI/RFI signals filtering and electrostatic discharge (ESD) protection. It features integrated TVS diodes that offer effective suppression of ESD voltages exceeding 15kV for air discharge and 8kV for contact discharge per IEC 61000-4-2, level 4 standards.
The device is suitable for use in portable communications devices such as cellular handsets and accessory kits. It provides filtering and protection for two I/O lines with low insertion loss up to approximately 10MHz and good attenuation at high frequencies from 100MHz to 1GHz.
| ESD Air Discharge Rating | 15 kV |
|---|---|
| ESD Contact Discharge Rating | 8 kV |
| TVS Reverse Stand-Off Voltage (Typical) | 5 V |
| Operating Temperature Range | -20 to +125 °C |
| Package Type | SC70-5L |
It provides bi-directional unwanted EMI/RFI signals filtering and electrostatic discharge (ESD) protection for two I/O lines.
The STF701 is suitable for cell phone handsets, cell phone accessories, RF communications equipment, laptop computers, two-way pagers, and GPS devices.
