Panasonic KX-FL501 High Speed Laser Fax with Copier Function Control Panel Layout Guide

About this manual

This text description outlines the physical arrangement of buttons and controls on the unit's interface. The panel is divided into three sections: left, middle, and right.

The left section contains a telephone keypad with a nib on the 5 button, followed by four circular buttons for REDIAL, HANDSET MUTE, FLASH, and MONITOR. The middle section features a display screen, ONE-TOUCH LABEL CARD, HELP, DIRECTORY PROGRAM, MENU, CALLER ID PRINT, CALLER ID SEARCH, IQ-FAX, JOG DIAL, COPY START, STOP, and FAX START buttons.

What's inside

• Finding the Controls
• Left part controls
• Middle part controls
• Right part controls
• Telephone keypad
• Display and Menu
• Copy functions
• Fax functions

Frequently asked questions

What does the nib on the 5 button indicate?

The text describes a specific modification to the standard telephone keypad layout.

How many jog steps are indicated by one click of the JOG DIAL?

Each click of the dial indicates exactly one jog step.
