CC BEC Pro is a high voltage RX power switching regulator with a maximum input voltage of 12S (50.4V) and a maximum output current of 20A. The adjustable output voltage is 4.8 to 12.5V.
The Castle Creations BEC Pro is a high voltage receiver power switching regulator designed for use in RC model applications. It features an adjustable output voltage ranging from 4.8V to 12.5V and a maximum output current of 20 amps. The device is compatible with various Castle Creations controllers including the Thunderbird, Phoenix, Phoenix Ice, Mamba, and Sidewinder series.
| Max Input Voltage (12S) | 50.4 volt S |
|---|---|
| Max Output Current | 20 amp |
| Adjustable Output Voltage | 4.8 to 12.5 volt S |
| Max Voltage (Cars) | 6S (25 v) |
| Max Voltage (Airplanes) | 10S (40 v) |
| Length | 1.69" (43mm) |
| Width | 1.3" (33mm) |
| Height | 0.94" (24mm) |
| Weight (w/o wires) | 1 oz (29 grams) |
The maximum output current is 20 amps.
The output voltage is adjustable from 4.8V to 12.5V.
No, the BEC Pro should never be operated in series or parallel with another BEC.
