Panasonic PT-47WX49 PT-47WX51 PT-56WX51 PT-65WX51 Operating Instructions

This manual describes the operating instructions of Panasonic PT-47WX49, PT-47WX51, PT-56WX51 and PT-65WX51 color video projection systems.

Brand: Panasonic
Category: Projector
Document type: User Manual
Language: English
Pages: 58
File format: PDF
File size: 2.3 MB
Published: 06 August, 2012
Updated: 30 September, 2023
MD5 checksum: B7F069B9DF1AE74C51E5FF2E33DC10DC
PDF: Panasonic PT-47WX49 PT-47WX51 PT-56WX51 PT-65WX51 Operating Instructions PDF

About this manual

This manual provides operating instructions for the Panasonic Color Video Projection System models PT-47WX49, PT-47WX51, PT-56WX51, and PT-65WX51. It includes safety warnings regarding electric shock and moving the set, as well as a feature chart detailing capabilities such as split-screen operation, closed captioning, and various input options.

What's inside

Feature Chart
Specifications
Care and Cleaning
Installation
Television Location
Optional Cable Connections
AC Power Supply Cord
Cable / Antenna
VCR Connection
Troubleshooting Chart

Specifications

Power Source	120V AC, 60Hz
Channel Capability	181 VHF-12; UHF-56; Cable-113
Video Input Jacks	1Vp-p, 75 Ohm, Phono Jack Type
Audio Input Jacks	500mV RMS 47K Ohm

Frequently asked questions

How should I move the television set?

Push from the left side of the set, as casters on the right do not pivot in all directions.

What type of cable should be used for connections?

Use 75-ohm coaxial shielded cables between components.
