The LT1945 is a dual micropower DC/DC converter from Linear Technology Corporation. It features a low quiescent current (20µA), high efficiency (90%+) and low standby current (<1µA). It is suitable for various portable applications.
The LT1945 is a dual micropower DC/DC converter in a 10-pin MSOP package, designed to generate well-regulated positive and negative outputs. It operates with input voltages as low as 1.2V and features a low quiescent current of 20µA in active mode and less than 1µA in shutdown mode.
| Quiescent Current (Active Mode) | 20µA |
|---|---|
| Quiescent Current (Shutdown Mode) | <1µA |
| Minimum Input Voltage | 1.2V |
| Switch Saturation Voltage | 250mV at 300mA |
| Maximum Output Voltage | +34V |
| Switch Current Limit | 350mA |
| Operating Temperature Range | -40°C to 85°C |
The quiescent current is 20µA in active mode and reduces to less than 1µA in shutdown mode.
The device operates with an input voltage as low as 1.2V.
The LT1945 is available in a 10-pin MSOP package.
