AD8222 is a precision dual-channel instrumentation amplifier that provides a 4mm×4mm package with low noise, high accuracy DC performance and excellent AC performance.
The AD8222 is a dual-channel, high performance instrumentation amplifier that requires only one external resistor per amplifier to set gains of 1 to 10,000. It is available in a small 4 mm × 4 mm LFCSP package, allowing for increased channel density and lower cost per channel without compromising performance. The device can be configured as a single-channel, differential output instrumentation amplifier to provide high noise immunity for remote sensors or to drive differential input ADCs.
| Gain Range | 1 to 10,000 |
|---|---|
| Input Voltage Noise | 8 nV/√Hz |
| Input Offset Voltage | 60 μV maximum |
| Minimum CMRR | 126 dB |
| Bandwidth | 140 kHz |
| Supply Range | ±2.3 V to ±18 V |
| Operating Temperature | -40°C to +85°C |
| Package Type | 4 mm × 4 mm LFCSP |
The gain is set with one external resistor per amplifier.
The minimum CMRR is 126 dB at a gain of 100.
Yes, it can be configured as a single-channel, differential output instrumentation amplifier.
