Hitachi CP-S220W Liquid Crystal Projector User's Manual

This manual introduces the features and characteristics of the CP-S220W liquid crystal projector.

Brand: Projector
Category: Projector
Document type: User Manual
Language: English
Pages: 28
File format: PDF
File size: 1.6 MB
Published: 02 August, 2012
Updated: 01 October, 2023
MD5 checksum: B21BB1E38D519921D70B4145ABCC3EA9
PDF: Hitachi CP-S220W Liquid Crystal Projector User's Manual PDF

About this manual

This user's manual covers the Hitachi CP-S220W liquid crystal projector, detailing its features such as outstanding brightness, partial magnification, and distortion correction. It includes instructions on loading the remote controller battery and identifying the various parts of the projector.

What's inside

Features
Contents of Package
Part Names
Loading the Battery
Installation
Cabling
Plug & Play
Basic Operations
Troubleshooting
Maintenance

Specifications

Projection Technology	Liquid Crystal
Lamp Type	UHB lamp
Compatible Signals	NTSC / PAL / SECAM video signals
Resolution Support	800 x 600 dots
Foot Adjuster Range	0° to 10°
Remote Battery Type	3V micro lithium battery Type no. CR2025

Frequently asked questions

What type of battery is required for the remote controller?

The remote controller requires a 3V micro lithium battery of Type no. CR2025.

Can the projector be installed in a vertical position?

No, it is recommended to use the projector at a horizontal position to prevent heat buildup and damage.

What is the range of the foot adjuster?

The projection angle can be adjusted within approximately 0° to 10°.
