Impact 64 LCD Panel User Guide

About this manual

The document is a user guide for the Impact 64 LCD panel, described as a state-of-the-art projection device suitable for displaying computer-generated text and graphics. It covers applications such as presentations, software training, and educational use.

The manual details the main features of the unit, including support for 64 greyshades, an infrared remote mouse (BatMouse), intelligent cooling systems, and compatibility with various computers via supplied cables and adapters.

What's inside

• Introduction
• Main Features
• Supplied Material
• Optional Material
• Setting Up the LCD Panel
• Using the LCD Panel
• Remote Control
• Front Panel
• Connectors
• Maintenance

Specifications

Frequently asked questions

What applications is the Impact 64 LCD panel suitable for?

The device is ideal for presentations, software training, educational use, advertising, and information boards.

How many greyshades can the Impact 64 display simultaneously?

The panel is capable of displaying 64 greyshades at the same time.

What power voltage is required for the LCD panel?

The unit requires a power supply of 5,12,5V.
