The SSM2211 is a high-performance audio amplifier that delivers 1 W RMS of low-distortion audio power into a bridge-connected 8 Ω speaker load, (or 1.5 W RMS into a 4 Ω load). It operates over a wide temperature range and is specified for single-supply voltages between 2.7 V and 5.5 V. When operating from batteries, it will continue to operate down to 1.75 V, making the SSM2211 the best choice for unregulated portable computers, personal wireless communicators, hands-free telephones, speakerphones, intercoms, musical toys and speaking games.
The SSM2211 is a high-performance audio amplifier designed to deliver 1 W RMS of low distortion audio power into a bridge-connected 8 Ω speaker load, or 1.5 W RMS into a 4 Ω load. It operates over a wide temperature range and is specified for single-supply voltages between 2.7 V and 5.5 V, with the ability to function down to 1.75 V when operating from batteries.
| Output Power (BTL, 4 Ω) | 1.5 W RMS |
|---|---|
| Output Power (BTL, 8 Ω) | 1 W RMS |
| Supply Voltage Range | 2.7 V to 5.5 V |
| Minimum Operating Voltage | 1.75 V |
| Bandwidth | 4 MHz |
| Phase Margin | > 80 Degrees |
| Total Harmonic Distortion (1 W, 8 Ω) | 0.2% THD |
| Operating Temperature Range | -20°C to +85°C |
| Shutdown Current | 100 nA |
The device can function down to 1.75 V when operating from batteries.
It delivers 1.5 W RMS into a 4 Ω load.
Yes, it is the best choice for unregulated applications such as toys and games.
