The PT5060 is a dual output integrated switching regulator from Power Trends. It offers a wide input voltage range and adjustable output voltage.
The Power Trends PT5060 Series is a dual output Integrated Switching Regulator (ISR) designed for use in +5 volt systems that require low power +12 or +15 volt rails. These regulators are suitable for powering applications such as D/A and A/D converters, Op Amps, and interface logic. The series is available in a low profile 12-pin SIP package in either vertical or horizontal through-hole or SMD configurations.
The device features a wide input voltage range and offers 85% efficiency. The output voltage for both rails can be easily adjusted using a single external resistor. However, the document notes that this product does not include short-circuit protection, and the boost topology ISRs are not short circuit protected. The operating temperature range is specified from -40°C to +85°C.
| Input Voltage Range | 4.75 - 5.5 V |
|---|---|
| Efficiency | 85 % |
| Switching Frequency | 650 kHz |
| Operating Temperature Range | -40 to +85 °C |
| Package Type | 12-pin SIP |
No, the document explicitly states that this product does not include short-circuit protection.
The maximum input voltage is 475 V.
The maximum operating temperature is +85 °C.
The weight is 65 grams.
