Crane RS Series Butterfly Valve Dimensions and Weights Datasheet

This document is the CENTERLINE-Absperrklappen Serie RS Abmessungen/Gewichte DN 40-600 RS/DB-0006-D/10.01/GP product manual, which mainly introduces the product's dimensions, weight, nominal pressure, thread, and accessories.

Brand: Crane
Category: Other
Document type: Datasheet
Language: German
Pages: 2
File format: PDF
File size: 103 KB
Published: 11 July, 2012
Updated: 30 September, 2023
MD5 checksum: 5621236126DFE439D92A5DD73454EFA1
PDF: Crane RS Series Butterfly Valve Dimensions and Weights Datasheet PDF

About this manual

This document provides technical data for Crane RS series butterfly valves, specifically detailing dimensions and weights. It covers nominal sizes from DN 40 to DN 600 and includes specifications for different housing materials (GGG/GS-C and GG) and pressure ratings (PN 10, PN 16, ANSI 150). This manual is written in German.

What's inside

Abmessungen
Gewichte
Ringgehause
Anflanschgehause
Klappe mit Handhebel
Klappe mit Getriebe
Klappe mit Revo Schwenkantrieb
Material
Nennweite
Druckstufe

Specifications

Nominal Size Range	DN 40-600
Document Reference	RS/DB-0006-D/10.01/GP

Frequently asked questions

What is the nominal size range for the Crane RS butterfly valve?

The valve is available for nominal sizes ranging from DN 40 to DN 600.

What is the weight of the handwheel version for a DN 100 valve?

The handwheel version weighs 46 kg for a DN 100 valve.

What is the weight of the REVO drive version for a DN 200 valve?

The REVO drive version weighs 56 kg for a DN 200 valve.
