This document is about the Potentiometer Posiflex F10/F20/F40 POT module. The module has the following features: maximum voltage of 315V, power of 1.0 Watt, and resistance of 1K Ohm. The module is used for wiring with positioners, trimmers, and customer connections. It enables the control function of the potentiometer.
This document is a technical specification sheet for a Potentiometer Module identified by drawing number Drw.nr. 363.95.005. The component features a resistance of 1KOhm and a maximum power rating of 1.0 Watt, with a voltage limit of 315 Vmax.
The datasheet indicates compatibility with Posiflex F10 / F20 / F40 systems. It includes multilingual wiring instructions for positioners in German, French, Spanish, and English.
| Maximum Voltage (U) | 315 Vmax. |
|---|---|
| Power Rating (P) | 1.0 Watt |
| Resistance (R) | 1KOhm |
| Drawing Number | 363.95.005 |
The resistance is 1KOhm.
Yes, the document lists compatibility for Posiflex F10 / F20 / F40.
