M1723A/B Monitor/Defibrillator is a compact, portable monitor/defibrillator. It combines a 360 joule defibrillator, ECG monitor, and annotating strip chart recorder in a compact, lightweight package.
The HP CodeMaster XL+ is a portable defibrillator and monitor that combines a 360-joule defibrillator, ECG monitor, and annotating strip chart recorder. It features a 5-inch screen, adjustable heart rate alarms, and can be powered by an internal battery or AC power. The device supports 3- and 5-wire patient cable ECG capabilities and includes optional transcutaneous external pacing.
| Output energy (delivered) | 2, 3, 5, 7, 10, 20, 30, 50, 70, 100, 150, 200, 300, and 360 joules |
|---|---|
| Waveform | Damped sinusoidal (Lown) |
| Display size | 5 inch diagonal (12.7 cm) CRT |
| Battery capacity | 4 Ah, 12 V nominal |
| Battery monitoring time | Approximately 2.5 hours |
The output energy ranges from 2 to 360 joules in increments of 2, 3, 5, 7, 10, 20, 30, 50, 70, 100, 150, 200, 300, and 360 joules.
Yes, the instruments are portable defibrillator/monitors powered by internal battery or AC power.
The device uses a rechargeable sealed lead-acid battery with a nominal voltage of 12 V and a capacity of 4 Ah.
