This document provides dimensional data for the Reggiane HTM series of pumps, specifically models HTM 15, HTM 31, and HTM 40. The pumps are available in PP (Polypropylene) and PVDF (Polyvinylidene Fluoride) materials and are designed for PN 10 flanges according to DIN standards.
The data sheet includes overall dimensions and specific motor dimensions for various configurations, including different power ratings (1.1 kW, 1.5 kW, 2.2 kW, 3 kW, 4 kW) and motor types (Geos, G100L, G100). It notes that the direction of rotation is counter-clockwise when facing the motor. This manual is written in Italian.
| Material | PP / PVDF |
|---|---|
| Flange Standard | DIN PN 10 |
| Direction of Rotation | Counter Clockwise |
| HTM 40 Motor Power | 3/4 kW |
The direction of rotation is counter clockwise as seen when facing the motor.
These pumps are available with either threaded or flanged connections.
