This document is a user manual for ZSA two-phase soft starter, which provides information on its technical specifications, installation, and operation instructions.
This document provides technical specifications and operational guidelines for the Horstmann ZSA series of two-phase soft starters designed for three-phase motors. The manual covers specific models including ZSA3, ZSA 5.5, ZSA 7.5, and ZSA 11/ZSA15, detailing their maximum motor loads, power consumption, and environmental operating conditions.
The guide includes detailed wiring diagrams for standard configurations and PLC integration, along with safety instructions for fuse selection. It also outlines the commissioning procedure, explaining how to adjust the start torque and acceleration time using internal trimmers and LEDs to optimize motor performance and prevent overheating. This manual is written in German.
| Max. Motorlast (kW) | 1.5/3, 5.5, 7.5, 11/5 |
|---|---|
| Netzfrequenz | 50 - 60 Hz |
| Leistungsaufnahme Elektronik | 1,6 VA |
| Betriebstemperatur | -15 °C — +40 °C |
| Relative Luftfeuchtigkeit | 0-90 %, nicht kondensierend |
| Schutzklasse Gehäuse | IP 40 |
| AnschluRquerschnitt (flexibel) | 2,5 qmm |
| Einstellbereiche An- und Auslaufzeit | max. 10 s |
| Anfangsmoment | 0-100 % |
The maximum motor load is 11 kW for the ZSA11 and 5 kW for the ZSA15.
The start torque is adjusted by turning the trimmer for start torque approximately 20 degrees clockwise from the left stop.
The device switches to Relay operation after the acceleration phase is completed, indicated by the LED changing from 'Triac' to 'Relais'.
