Jenaer 23S Series Brushless DC Motor Technical Data Sheet

ECOSTEP® - 23S 2-2 series motors, technical data sheet

Jenaer 23S Series Brushless DC Motor Technical Data Sheet - cover page
Brand
Jenaer
Category
Motor
Document type
Datasheet
Language
German
Pages
2
File format
PDF
File size
436 KB
Published
10 July, 2012
Updated
30 September, 2023
MD5 checksum
9E56AD66DD2376998F7072001A494472
PDF
Jenaer 23S Series Brushless DC Motor Technical Data Sheet PDF

About this manual

This document provides technical specifications for the Jenaer 23S series of brushless DC motors. It lists performance characteristics such as peak torque, rated torque, maximum speed, and current ratings across various models in the series.

The datasheet also covers details regarding incremental and absolute encoders compatible with these motors, including resolution options (from 8,000 to 160,000 pulses per revolution) and specific wiring configurations for motor and encoder cables. This manual is written in German.

What's inside

  • Encoderanschluss
  • Bemessungswerte
  • Technische Daten Motor
  • Technische Daten Inkrementalencoder
  • Haltebremse
  • Encodertyp
  • Kupplungssatz
  • Anschluss Ader Pin

Specifications

Maximum Interlink Voltage60V or 90V DC
Operating Voltage (Encoder)5V DC (+/-10%)

Frequently asked questions

What is the maximum axial load for the motor?

The maximum axial load is 80 N.

What is the maximum operating speed for the 5P incremental encoder?

The maximum speed for the 5P incremental encoder is 1500 U/min.
