The RB5C634A is a one-chip coder equipped with image compression function of generating JPEG2000-compliant codes and decompression function of decoding images from the JPEG2000-compliant codes. It provides powerful encoding and decoding functionality by simply setting up parameters in the internal registers. This coder can process an image of up to 1024 x 1024 pixels within one tile, which presents the ideal solution for reducing the degradation in image quality to a large extent.
The Ricoh RB5C634A is a one-chip coder equipped with image compression functionality for generating JPEG2000-compliant codes and a decompression function for decoding images from these codes. It supports processing images up to 1024 x 1024 pixels within one tile and includes rate control to manage compressed code size. The device features selectable wavelet filters (R5-3 or IRQ-7) and automatically generates necessary headers during compression and interprets them during decompression.
| Image Size | Up to 1024 x 1024 pixels |
|---|---|
| Wavelet Filter | R5-3 or IRQ-7 |
| Processing Speed (with truncation) | 31M pixels/sec |
| Processing Speed (without truncation) | 27M pixels/sec |
| Package | 272-pin BGA |
| Operating Temperature | 0 to 70 °C |
| Supply Voltage (VCC) | 1.62 to 1.98 V |
| Supply Voltage (VCC2) | 3.0 to 3.6 V |
The device can process images of any size up to 1024 x 1024 pixels in one tile.
The RB5C634A supports the R5-3 filter and the IRQ-7 filter.
The maximum processing speed with truncation is about 31 million pixels per second.
