The HI 93730 Molybdenum ISM is an instrument used to detect molybdenum content. It is warranted for two years against defects in workmanship and materials. It should be maintained according to the instructions and does not cover damages due to accident, misuse, tampering or lack of prescribed maintenance. If service is required, contact the dealer from whom you purchased the instrument. If under warranty, provide the model number, date of purchase, serial number and nature of the failure. If the repair is not covered by the warranty, you will be notified of the charges incurred. If the instrument needs to be returned to Hanna Instruments, obtain a Returned Goods Authorization Number from the Customer Service department and send it with prepaid shipment costs. Proper packaging is important when shipping the instrument. To validate the warranty, fill out and return the enclosed warranty card within 14 days from the date of purchase. All rights reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner, Hanna Instruments Inc., Woonsocket, Rhode Island, 02895, USA. Thank you for choosing a Hanna product.
The HI 93730 is an instrument designed to measure molybdenum content in water and wastewater within a range of 0.0 to 40.0 mg/L (ppm). It utilizes the mercaptoacetic acid method, where the reaction between molybdenum and reagents creates a yellow tint in the sample for detection by a silicon photocell.
The manual details the measurement procedure involving specific reagents (HI 93730A-0, B-0, C-0) mixed with the sample. It also covers operational features such as auto-shut off after 10 minutes of non-use, battery replacement using a 9V alkaline battery, and troubleshooting display codes for errors like 'Under range' or 'Over range'.
| Range | 0.0 to 40.0 mg/L |
|---|---|
| Resolution | 0.1 mg/L |
| Accuracy | +/-0.3 mg/L +5% of reading |
| Light Source | LED @ 470 nm |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Battery Type/Life | 1 x 9 volt/40 hours |
| Dimensions | 180 x 83 x 46 mm |
The meter measures molybdenum content in water and wastewater in the 0.0 to 40.0 mg/L (ppm) range.
A 9V alkaline battery is required, with a typical life of 40 hours.
Interference may be caused by Aluminum above 50 mg/L, Chromium above 1000 mg/L, Copper above 10 mg/L, and others.
