The NRV10 is an 8x2 analog mixer with a 10 x 10 FireWire digital audio interface and effects. This product has various features and technical specifications.
The M-Audio NRV10 is a high-quality analog mixer integrated with a professional 10-channel FireWire digital audio interface. It combines eight line-level inputs and five XLR microphone inputs with switchable phantom power into a compact unit suitable for project studios or live recording setups.
The device features an integrated digital effects processor supporting reverbs, delays, chorus, and flange effects via front panel rotary switches. It allows users to record up to ten channels of audio directly into a computer-based DAW at sample rates up to 96kHz and bit-depths up to 24 bits, while also routing audio from the DAW back to the mixer's analog channels.
| Line Inputs | Eight 1/4" balanced TRS line inputs |
|---|---|
| Mic Inputs | Five balanced XLR mic inputs |
| Digital Effects Settings | 256 settings |
| Effects Sends | Two mono effects sends |
| Effects Returns | Two stereo effects returns |
| Main Outputs | Balanced XLR and 1/4" main outputs |
| Sample Rate Support | up to 96kHz |
| Bit-depth Support | up to 24 bits |
The integrated DSP section provides reverbs, delays, chorus, flange and more.
The interface supports high-resolution sample rates of up to 96kHz.
The device is supported under Windows XP with Service Pack 2 or later and Mac OS X version 10.3.9 or 10.4.7.
The system requires a minimum of 512MB RAM.
