Agilent Canine Oligo Microarray is a microarray product produced by Agilent company for research of canine genetic diseases. It contains 42,034 (60-mer) probes, which can fully cover the Canis familiaris genome.
Agilent's Canine Oligo microarray is designed for research on *Canis familiaris* (domestic dog) to study genetic bases of diseases such as cardiology, cancer, and diabetes. The array contains 42,034 probes representing predicted genes based on public data sources including RefSeq, Unigene, Ensembl, and TIGR.
The microarray features a comprehensive coverage of the canine genome on a single 1x3 inch glass slide using 60-mer oligonucleotide probes. It offers high sensitivity for detecting low expression levels and consistent feature quality. The product includes specifications for probe length, orientation, detection sensitivity, dynamic range, and RNA sample requirements.
| Number of features | 44,290 |
|---|---|
| Represented genes/probes | 42,034 |
| RNA requirement (two-color) | 50 ng total RNA |
| RNA requirement (one-color) | 200 ng total RNA |
The Canis familiaris Oligo Microarray has the part number G2519A option 004.
The system uses Cyanine 3 and Cyanine 5 fluorescent labeling.
200 ng of total RNA is required for one-color processing.
