Legacy ML3215/ML3245 ProLine Series Operating Instructions

This document provides operating instructions for the ProLine series ML3215 / ML3245 radios from Topaz3, including information about the features and operation of the equipment.

Brand: Legacy
Category: Other Electronics
Document type: User Manual
Language: English
Pages: 20
File format: PDF
File size: 420 KB
Published: 02 July, 2012
Updated: 29 September, 2023
MD5 checksum: 7B15E426678399F2D93613DF08463708
PDF: Legacy ML3215/ML3245 ProLine Series Operating Instructions PDF

About this manual

This manual provides operating instructions for the Legacy ProLine Series mobile radios, specifically the ML3215 (VHF) and ML3245 (UHF) models. These fully programmable, synthesized radios feature an 8-character alphanumeric display and support 32 channels with output power options of 2 or 45 watts. The device includes various communication features such as channel scanning, CTCSS/DCS tones, VOX operation, and public address mode.

What's inside

FCC RF Exposure Compliance
Safety Information
About Topaz3
About Your Legacy ProLine Radios
Unpacking and Checking Equipment
Radio Control Buttons / Operation Features
Radio Operation
Radio Functions
Mode Operation and Function Setup
Licensing and Service Information

Specifications

Frequency Bands	VHF and UHF
Channels	32 Channels
Display	8-Character alphanumeric
Output Power	2 or 45 Watts
CTCSS Tones	38 Standard and nonstandard
DCS Codes	104
Power Input	13.8V DC

Frequently asked questions

What is the maximum antenna gain allowed?

The antenna gain must not exceed 3 dBd.

What is the maximum duty cycle for transmission?

Do not transmit for more than 50% of total radio use time.

What is the minimum separation distance for bystanders?

Maintain a minimum separation distance of 5 feet (17 meters) between persons and the antenna.
