The Yamaha DK-40B Electone is a musical instrument featuring five keyboards: Upper Manual, Lower Manual, Pedals, Solo Manual, and Portamento. The instrument allows for playing melody, chords, and bass simultaneously, with special capabilities for solo lines and unique sound effects via the Portamento manual.
| Upper Manual Range | 4 octaves c ~ c4 |
|---|---|
| Lower Manual Range | 4 octaves C ~ c3 |
| Pedals Range | 1 octave Ci~C |
| Solo Manual Range | 3 octaves c ~ c3 |
| Total Output Power | 90 watts |
| Power Consumption | 150 watts |
| Power Source | 100/110/117/125/220/240V AC 50/60Hz |
| Width | 117 cm (46") |
| Height | 99 cm (39") |
The DK-40B has five keyboards: the upper four are called manuals (solo, portamento, upper, and lower), and the bottom one is for the pedals.
If two or more voice selector tabs are pressed, the one to the right takes precedence.
No, except for the Astro tab, all Portamento voice selector tabs can be combined with each other. If the Astro tab is set, it cancels all the others.
The finish is Natural American Walnut.
