This manual provides information on how to use the AV receiver R-V702/R-V502, as well as precautions and other information.
This Owner's Manual covers the Yamaha R-V7020 and R-V502 Natural Sound AV Receivers. It includes safety instructions, a list of supplied accessories, and a profile of the unit's features such as 5-speaker configuration, Dolby Pro Logic Surround Decoder, and Cinema DSP technology.
The guide details speaker setup, connection procedures, and the functions of various controls. It also explains basic operations, tuning procedures for FM/AM stations, the use of the Digital Sound Field Processor (DSP), and how to set the SLEEP Timer. A troubleshooting section and technical specifications are also included.
| RMS Output Power (U.S.A. models) | 80W + 80W (8Q) RMS Output Power, 0.09% THD, 1 kHz |
|---|---|
| Rear Output Power | 20W + 20W (8Q) RMS Output Power, 0.7% THD, 1 kHz |
| Surround Decoder | Dolby Pro Logic Surround Decoder |
| Sound Processing | CINEMA DSP |
The supplied accessories include an Indoor FM Antenna, Batteries (size AA, R6, UM-3), and a Remote Control Transmitter.
The receiver supports a 5 Speaker Configuration.
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them.
