This manual provides instructions for the Yamaha Solo Synthesizer SY-1, a musical instrument featuring 28 preset instrumental tones and various modification controls. It details how to connect the unit to organs or amplifiers, operate the 37-key keyboard, and adjust parameters such as filter, envelope, and vibrato.
| Keyboard Range | 37 keys c to ca |
|---|---|
| Total Range | six octaves |
| Power Consumption | 20 Watts |
| Power Source | AC, 50/60Hz |
| Dimensions (Width) | 78cm (30") |
| Dimensions (Depth) | 28cm (11") |
| Dimensions (Height) | 16.5cm (6 1/2") |
| Weight | 12kg (26 lbs.) |
The available voltage settings are 110, 130, 220, and 240V.
The pitch can be raised or lowered about 100 cents (one semitone).
