Agilent G1978A Multimode Source for LC/MS 6300 Ion Trap Set-Up Guide

This document provides a configuration guide for the Agilent Technologies Agilent G1978A multimodal source for the Agilent 6300 LC/MS with ion traps, including features and characteristics of the product.

Brand: Agilent
Category: Other
Document type: Installation Guide
Language: French
Pages: 68
File format: PDF
File size: 7.6 MB
Published: 08 June, 2012
Updated: 28 September, 2023
Model: G1978A
MD5 checksum: 144A90EA455E6A9AEA156685A76E39B8
PDF: Agilent G1978A Multimode Source for LC/MS 6300 Ion Trap Set-Up Guide PDF

About this manual

This document serves as a set-up guide for the Agilent G1978A multimode source designed for Agilent 6300 series ion trap LC/MS instruments. It details the installation process, including hardware replacement of specific cards (GELV-5 and GEPS-2) and the installation of the TrapControl software version 6.1. The guide also covers converting existing ESI, APCI, or APPI sources to multimode configurations. This manual is written in French.

What's inside

Installation
Performance Verification
Methods
Source Conversion
Software Installation
Hardware Replacement
Troubleshooting

Specifications

Compatible Software	ChemStation version B.01.03 minimum
Required Software	TrapControl version 6.1
Hardware Requirement	Thermocontacts

Frequently asked questions

Which instruments are compatible with the G1978A source?

The source is compatible with Agilent 6300 series ion trap LC/MS instruments.

What software is required to operate the multimode source?

The TrapControl software version 6.1 is required for operation.

Which hardware cards must be replaced during installation?

The old GELV and GEPS-1 cards must be replaced with GELV-5 and GEPS-2 cards.
