The AD7884/AD7885 is a 16-bit monolithic analog-to-digital converter with features such as high internal sampling rate, fast conversion speed, and low power consumption. It is suitable for applications in automatic test equipment, medical instrumentation, industrial control, data acquisition systems, and robotics.
The document describes the AD7884/AD7885 family as monolithic analog-to-digital converters featuring a two-pass flash architecture for fast conversion. Key characteristics include a 16-bit resolution, a maximum throughput rate of 166 kSPS, and an internal sample-and-hold circuit. The devices support both +5 V and +3 V input ranges.
| Resolution | 16 Bits |
|---|---|
| Conversion Time | 5.3 us max |
| Throughput Rate | 166 kSPS max |
| Signal to (Noise + Distortion) Ratio | 84 dB min |
| Power Dissipation | 325 mW max |
The maximum throughput rate is 166 kSPS.
Two input ranges are available: +5 V and +3 V.
Commercial Plastic (A, B Versions) operate from -40°C to +85°C.
