On-Board PC-SERIES Single Output DC-DC Converter Datasheet

This document introduces the features and characteristics of the PC-SERIES single output DC-DC converter, including input/output isolation, 5 dimensions shield metal case, over current protection, adjustable output voltage, and remote ON/OFF control.

Brand: LAMBOA
Category: DC/DC Converter
Document type: Datasheet
Language: English
Pages: 4
File format: PDF
File size: 358 KB
Published: 05 June, 2012
Updated: 29 September, 2023
MD5 checksum: 66622B86658385990A9808C37AFC5199
PDF: On-Board PC-SERIES Single Output DC-DC Converter Datasheet PDF

About this manual

This document provides specifications for the On-Board Type Power Supply PC-SERIES, a single-output DC-DC converter available in 1.5W, 3W, and 6W types. It details various input voltage ranges (5V to 48V) and adjustable output voltages including 3.3V, 5V, 12V, and 15V options.

What's inside

Features
Specifications
Terminal Connection
Outline Drawing
PCD-SERIES Dual Output

Frequently asked questions

What are the operating temperature limits for these converters?

The units operate from –20 to +70°C, with reduced power ratings at higher temperatures.

How long can the converter handle an overload or dead short?

You must avoid operating an overload or dead short for more than 30 seconds.

What is the withstand voltage between input and output?

The converter withstands 500VAC between input and output for 1 minute.
