PV1R5 and PV3 are single-in-line DC-DC converters with 1.5W/3W output power. They are input/output isolated, with adjustable output voltage, over current protection, and can be used in a wide range of applications.
The Lambda PV-Series offers single in‑line DC‑DC converters in 1.5 W and 3 W versions. Each model provides input‑output isolation, over‑current protection and an adjustable output voltage via a TRM terminal.
The datasheet lists detailed electrical parameters, wiring diagrams and terminal pin assignments for both single‑output (PV‑ series) and dual‑output (PVD‑ series) configurations, along with operating temperature and cooling information.
| Input Voltage | 5 VDC–48 VDC (model dependent) |
|---|---|
| Output Voltage | 5 V to 12 V (adjustable ±5 %) |
| Output Current (max) | 0 ~ 300 mA (1.5 W) / 0 ~ 600 mA (3 W) |
| Output Power (max) | 1.5 W (PV1R5) / 3 W (PV3) |
| Withstand Voltage | 500 VAC for 1 minute |
| Cooling Method | Convection cooling |
| Operating Temperature | -20 °C to +70 °C |
The input voltage range is 5 VDC (4.5–9.0 V) up to 48 VDC (36–72 V) depending on the model.
Output voltage can be adjusted by the TRM terminal on the connector.
