This document describes the types, specifications, and characteristics of multi-layer ceramic capacitors, as well as how to place orders. It provides detailed explanations of the capacitance value, tolerance, dielectric, size, electrode material, and packaging method of the capacitors. These capacitors offer high accuracy, reliability, and stability, making them suitable for various electronic devices.
This document provides technical data for Multi-Layer Ceramic Capacitors (MLCCs) available in COG, X7R, Z5U, Y5V, and other dielectric types. It covers typical performance characteristics such as temperature coefficients, dissipation factors, and insulation resistance.
The datasheet includes ordering instructions with specific codes for capacitance, tolerance, voltage, terminal material, and packing type (Bulk or Reel). Detailed dimension charts are provided for various SMD sizes (e.g., 0603, 1206) and Radial/Axial leaded packages.
| Temperature Range (COG/X7R/Y5V/Z5U) | -55°C to 125°C |
|---|---|
| Dissipation Factor (COG) | < 0.001 @ 1MHz, 25°C |
| Quality Factor (COG) | > 1000 |
| Insulation Resistance | > 1000 MΩ or 1000 GΩ |
| Dielectric Strength | > 2.5 VDCW, 50mA Max |
The standard configuration uses Palladium Silver internal electrodes, Nickel intermediate layers, and Solder external plating.
The specified temperature range for COG capacitors is -55°C to 125°C.
The maximum dissipation factor is 0.025 (2.5%) when tested at 1KHz and 25°C.
The dimensions for a CS3216 capacitor are 3.20° by 0.25.
