Update: 28 September, 2023
The LT8610 and LT8611 are 42V, 2.5A synchronous step-down regulators that meet the stringent high input voltage and low output voltage requirements of automotive, industrial and communications applications. By replacing an external Schottky diode with an internal synchronous power switch, the solution size is minimized and efficiency is increased while reducing power dissipation. These regulators are designed to be compact and allow inductor size to be selected based on the output load requirements of the application, providing short-circuit robustness.
File format: PDF
Size: -
MD5 Checksum: 39F84BCA34B18E058D5CFFAFD88FDF02
Publication date: 05 June, 2012
Downloads: -
PDF Link: LINEAR 42V 2.5A Synchronous Step-Down Regulator with 2.5 A Quiescent Current Design Note 504 PDF
