ViewSonic E71f monitor, with a stylish appearance and ultra-thin screen, has a maximum resolution of up to 1280 x 1024 and an ultra-fine dot pitch of 0.21mm, which can provide excellent image clarity and contrast.
The ViewSonic E71f 17" CRT monitor features the PerfectFlat® screen technology with a 0.21 mm horizontal dot pitch and ultra‑flat anti‑glare coating, delivering a maximum resolution of 1280 × 1024. It includes OnView® controls, ViewMatch® color tuning, OSD/Power Lock, and Plug‑and‑Play support for Windows and Mac systems.
Technical specifications include a 17" (16.0" viewable) screen, 75 W typical power consumption, AC 100‑240 V input, dimensions of 410 mm × 473 mm × 421 mm, weight of 16.0 kg, and multiple refresh‑rate options. The monitor is MPRII and Energy Star certified and meets UL, CSA, CUL, FCC, and other regulatory standards.
| Screen size | 17" (16.0" viewable) |
|---|---|
| Maximum resolution | 1280 × 1024 |
| Dot pitch | 0.21 mm horizontal, 0.25 mm diagonal |
| Input signal | Video RGB analog (75 Ω, 0.7/1.0 V p‑p) |
| Power consumption | 75 W (typical) |
| Power voltage | AC 100‑240 V, 50/60 Hz |
| Weight | 16.0 kg (35.27 lb) |
| Dimensions (W × H × D) | 410 mm × 473 mm × 421 mm |
| Refresh rates | 1280×1024 @ 66 Hz, 1024×768 @ 87 Hz, 832×624 @ 106 Hz, 800×600 @ 110 Hz, 640×480 @ 133 Hz |
| Compatibility | PC VGA and Mac PowerMac up to 1280 × 1024 |
The monitor supports a maximum resolution of 1280 × 1024.
Yes, the OSD/Power Lock function can be activated to prevent changes to monitor settings.
It operates on AC 100‑240 V, 50/60 Hz and typically consumes 75 W.
Yes, it works with PC VGA and Mac PowerMac systems up to a resolution of 1280 × 1024.
