This manual introduces the basic functions, features and usage of the AACBEEZZ PRO5301/5302 IP Phone.
This manual introduces the ACBEZ PRO5301/5302 IP Phone, a full‑featured VoIP telephone that supports both IP and PSTN lines. It describes the hardware layout, key functions, and basic operation such as making calls, holding, transferring, and using speed‑dial keys.
The guide covers detailed configuration methods, including LCD menu setup, web‑based management, and Telnet commands. It also explains firmware upgrade procedures, network settings, and advanced features like codec selection, LED status indicators, and call handling options.
| Ethernet ports | 2 RJ‑45 sockets for 10/100Base‑T |
|---|---|
| PSTN port | 1 RJ‑11 socket |
| Display | 24‑character dot matrix LCD (2 lines) |
| Audio codecs | G.711 a/wlaw, G.723.1 (6.3 kbps), G.729 family |
| LED status indicators | Speaker, Hold, Mute, Message, PSTN |
Network settings can be configured through the LCD menu, the web interface, or Telnet commands.
The phone provides two RJ‑45 Ethernet ports for 10/100Base‑T and one RJ‑11 port for PSTN connection.
Press the HOLD key; the phone uses the H.450 hold function to place the call on hold.
