XIO2001 is a PCI Express™ to PCI bus translation bridge with various features and characteristics.
The X102001 PCI Express™ to PCI Bus Translation Bridge data manual provides detailed information on the device’s features, protocol descriptions, electrical characteristics, and mechanical data. It includes sections on power‑up/down sequencing, bridge reset features, PCI Express and PCI bus interfaces, and GPIO control.
The document also contains ordering information, terminal assignments, a glossary of terms, and a comprehensive list of registers and capabilities. Mechanical drawings of the ZAJ (S‑PBGA‑N144) package are provided, along with safety and warranty notices from Texas Instruments.
| Literature Number | SCPS212B |
|---|---|
| Revision Date | July 2009 |
| Package Type | ZAJ (S-PBGA-N144) |
The literature number is SCPS212B.
The manual was revised in July 2009.
