This document describes the features and characteristics of the OS P 50 G3VM-21GR1 MOS FET relay, including low C×R value, load voltage of 20V, and a conduction resistance of 1Ω that suppresses output signal attenuation.
This manual describes the G3VM-21GR1 MOS FET solid‑state relay, covering its purpose, installation guidelines, and safety precautions.
Key specifications such as on‑state resistance, leakage current, forward LED current, and operating temperature limits are provided, along with wiring diagrams and application examples. This manual is written in Japanese.
| On‑state resistance (typical) | 1 Ω |
|---|---|
| On‑state resistance (maximum) | 1.5 Ω |
| Leakage current (max) | 1.0 nA |
| Forward LED current | 50 mA |
| Operating temperature range | -20 °C to 85 °C |
The maximum leakage current is 1.0 nA.
It operates from –20 °C to 85 °C.
Typical on‑state resistance is 1 Ω.
