15W AC to DC Switching Power Adapter Specification.
This document details the design and performance of the ONTOP SALII5A-1510U-6 AC to DC switching power adapter. It includes mechanical drawings, environmental limits, and reliability data such as MTBF of 100,000 hours at 25 °C.
Key electrical specifications are listed, including input voltage range, output voltage and current, efficiency, regulation, and protection features. Safety and EMC test results are also provided, along with mechanical dimensions and wiring details.
| Input Voltage (Rated) | 100~240 Vac |
|---|---|
| Input Frequency | 47~63 Hz |
| Input Current (Max) | 400 mA @ 100Vac/50Hz |
| Line Regulation | < +2% @ full load |
| Load Regulation | < +5% |
| Efficiency (100Vac) | ≥ 80% |
| Efficiency (240Vac) | ≥ 75% |
| Ripple & Noise Voltage | < 150 mVp‑p |
| Hi‑Pot Test Voltage | 3000 Vac |
| Insulation Test Voltage | 500 Vdc |
| Temperature Rise Limit | ≤ 45 °C case surface |
| Hold Up Time | 2.8 ms @ 100Vac |
| Rise Time | ≤ 20 ms @ 100Vac |
| Inrush Current | < 7 A @ 100~240Vac |
| No‑load Power Consumption | 31 W @ 240Vac |
| Operating Temperature | 0 °C ~ +40 °C |
The adapter accepts a rated input voltage of 100 to 240 Vac.
