Wiha Torque VDE screwdrivers provide maximum safety for electrical applications and precise and high repeat accuracy. The slimTECHNOLOGY design allows effortless access to low-lying fastening/ spring elements.
The Wiha TorqueVario‑S VDE is a precision torque screwdriver designed for electrical applications up to 1000 V AC. It features an ergonomic multi‑component handle with a micro‑fine surface and an integrated window scale for setting torque values from 0.6 Nm to 8.0 Nm.
The tool includes interchangeable VDE‑rated blades (slotted, Phillips, Pozidriv, Torx) and meets multiple safety standards such as IEC 60900:2004, EN ISO 6798 and BS EN 26789. Each screwdriver is individually tested for insulation up to 1000 V AC (GS‑mark) and 1500 V DC, and comes with a factory calibration certificate.
| Torque range | 0.6 Nm – 8.0 Nm |
|---|---|
| Insulation voltage | 1000 V AC (GS‑mark), 1500 V DC |
| Accuracy | +6 % (traceable to national standards) |
| Compliance standard | IEC 60900:2004 |
| Tip standard | DIN ISO 2380 / DIN ISO 8764 |
| Blade material | Chrome‑vanadium‑molybdenum steel, through‑hardened |
| Handle material | Cellulose acetate with micro‑fine surface structure |
| Audible click | Yes, when preset torque is reached |
It is insulated for up to 1000 V AC (GS‑mark) and up to 1500 V DC.
Torque is set via the integrated window scale using the supplied Torque‑Setter setting tool.
Interchangeable blades include slotted, Phillips, Pozidriv, Torx, and other VDE‑rated types.
