The AD6600 is a dual-channel, 20 MSPS mixed-signal receiver chip that supports 70 MHz to 250 MHz IF input frequencies and is designed for use in PCS/cellular base stations, GSM, CDMA, TDMA, wireless local loop, and fixed access applications.
The AD6600 is a mixed‑signal receiver chip that directly samples analog input frequencies from 70 MHz to 250 MHz. It features dual IF inputs, a 450 MHz track‑and‑hold, an 11‑bit, 20 MSPS ADC, digital RSSI outputs, an A/B channel indicator and a 2× clock output, all on a single LQFP package.
The document includes detailed DC and AC specifications, timing and switching requirements, absolute maximum ratings, pin descriptions, and an ordering guide. It is intended for designers of communications receivers, PCS/Cellular base stations and other wireless applications.
| Analog Input Frequency Range | 70 MHz–250 MHz |
|---|---|
| ADC Resolution | 11 Bits |
| DVCC Supply Voltage | 3.3 V |
The device is rated for operation from –40 °C to +85 °C.
