Describes the features and characteristics of Neutrik ® circular connector program series products, including connection methods, port numbers, metal housing, front or rear mounting, anti-pull off function, gold plating, soldering or crimping methods
Neutrik’s circular connector program offers a range of metal, multi‑pole connectors for industrial use. The series – powerCON, nanoCON, miniCON and neutriCON – include male and female cable connectors and receptacles that can be terminated by soldering, crimping, or mounted on printed‑circuit boards. Features such as a self‑locking quick‑lock system, robust all‑metal housing, and gold‑plated contacts ensure reliable connections.
The catalog lists technical specifications, ordering codes, accessories, and recommended assembly tools for each series. It also details certifications (UL, CUL, VDE, SEV) and environmental ratings such as temperature range and IP protection.
| Number of contacts | 1 to 12 |
|---|---|
| Rated voltage | 250 V ac (powerCON), 50 V ac (nanoCON, miniCON, neutriCON) |
| Dielectric strength | 4000 V de (powerCON), 1000 V de (nanoCON, miniCON), 1500 V dc (neutriCON) |
| Contact resistance | < 3 mΩ (powerCON, nanoCON), < 12 mΩ (miniCON), < 8 mΩ (neutriCON) |
| Temperature range | -30 °C to +80 °C |
| Protection class (IP) | IP20 (mated), IP2X (unmated), IP40‑IP5X (neutriCON) |
They operate from –30 °C up to +80 °C.
