DSL-504 ADSL router user's guide, introduces the router's features, including PPP, DHCP, NAT, VPN, TCP/IP, RIP-1/RIP-2, static routing, default routing, ATM, G.hs, high performance, full network management, Telnet connection, easy installation, etc
This guide explains how to install and set up the D-Link DSL-504 ADSL Router, covering hardware installation, power and line connections, and the web‑based configuration interface. It also describes the router’s features such as PPP security, DHCP, NAT, VPN, and routing protocols.
Additional sections cover advanced settings like firewall filters, static IP configuration, firmware upgrades, and warranty information, along with regulatory notices for FCC, CE, and VCCI compliance.
| Maximum downstream speed | 8 Mbps |
|---|---|
| Maximum upstream speed | 800 Kbps |
| Ethernet LAN ports | 4 RJ‑45 ports |
| ADSL line connector | RJ‑11 |
| PPP support | Yes |
| DHCP support | Yes |
| NAT support | Yes |
| VPN support | Yes |
The router’s web‑based management software works with any PC running Microsoft® Windows® 95, Windows 98, Windows 98 SE, Windows ME, Windows 2000, or Windows NT 4.0.
Yes, a micro‑filter (low‑pass filter) should be installed for each telephone that shares the line with the ADSL connection.
The DSL‑504 provides four dedicated Ethernet LAN ports with standard RJ‑45 connectors.
