This is a 1W LED product with the highest lumen per watt, long operational life, white or black housing, superior ESD protection, instant light (less than 100ns), compatibility with Luxeon's "Lambertian", etc. It is suitable for accent light/down light/spot light, automotive exterior/interior light, large area LCD backlight, reading light, marine/miner's lighting, portable flashlight/general lighting, etc.
The BriLux 1W Lambertian Emitter from Brilliance Technologies offers high lumen per watt, long operational life, and superior ESD protection. It is available in multiple colors (white, blue, green, yellow, amber, red) with selectable CCT ranges from 2800 K to 8000 K and typical flux of 140 lm at 350 mA.
The datasheet lists absolute maximum ratings, such as a continuous forward current of 350 mA, peak pulsed current of 1000 mA, and operating temperature from –30 °C to +110 °C. Recommended handling includes ESD precautions, heat‑sink attachment, and a soldering limit of 240 °C for up to 5 seconds.
| Power Dissipation (W) | 0.77–1.22 |
|---|---|
| DC Forward Current (mA) | 350 mA |
| Peak Pulsed Forward Current (mA) | 1000 mA |
| Reverse Voltage (V) | 5 V |
| ESD Sensitivity (V) | 2000 V |
| LED Junction Temperature at 350 mA (°C) | 125 °C |
| Thermal Resistance Junction‑to‑Board (°C/W) | 15 °C/W |
| Operating Temperature (°C) | -30 to +110 |
| Storage Temperature (°C) | -40 to +120 |
The continuous DC forward current is rated at 350 mA.
Lead soldering should be performed at 240 °C for a maximum of 5 seconds.
The device can operate from –30 °C up to +110 °C.
